Shanghai veins Electronic Technology Co., Ltd. is a commitment to the consumer electronics, IT electronics, power tools and LED lighting product design and manufacturing switching power adapter, charger, LED driver (CV / CC) power supplies, linear power supply, high frequency transformers, inductors, filters and other products supporting the production of private technology enterprises. For several years we continue to struggle with the spirit of the pulse treasure efforts the company developed a series of positive and negative pulse smart charger. Suitable for scooters, electric bicycles, electric motorcycles, three / four-wheeled vehicle parts and other fields. The company regards product quality of life and established a strict quality control and testing system, product failure rates to the lowest in the industry ...

The charger is suitable for electric vehicles, electric sightseeing cars, golf carts, electric forklifts, electric cars, electric forklift trucks,

Electric buses, electric boats, electric scooters, electric tricycle, adobe electric cars, electric field operations work, the engine rechargeable battery pack and other lead-acid batteries.

I. Related technical parameters

1. Intelligent Charging: AC 165V-260V between normal charge, without manual adjustment. This charger using pulse width modulation (PWM) circuit, according to the battery characteristics, the charging process controlled by the CPU, is divided into six stages,

Ensure fast charging, reduce curing, dehydration less summer, winter, charges to full, normal use can extend the battery make

Life of 3-6 months.

2. The current protection: output current will not change due to load changes, and always at the most current charging.

3. reversal protection: The charger plug reversed, battery cable reversed or shorted cable, the charger automatically shut down, automatically charged after troubleshooting.

4. Temperature compensation: ambient temperature at 35 - at - (18 ) when the motor voltage is automatically adjusted to compensate for temperature change

And lead to the battery charge is low or overcharging.

5. Timing function: each charge process are set timer to prevent overcharging the battery, the charger does not shutdown current angle.

6. Over-temperature protection: When the charger internal temperature is too high, the charger automatically charging current when the temperature returns to normal, automatic charging.

7. Energy efficient: unique circuit design, power 89%, compared with its charger cable, it can save 1-2 to complete a charge of electricity.

Second, the use

The charger is suitable for electric vehicles, electric sightseeing cars, golf carts, electric forklifts, electric cars, electric forklift trucks,

Electric buses, electric boats, electric scooters, electric tricycle, adobe electric cars, electric field operations work, the engine rechargeable battery pack and other lead-acid batteries.

Third, the principle of charging

Precharge the first paragraph: Charging lights lit, the charger is charging current when the voltage rises to a set value or longer than 15 minutes into the second stage.

The second paragraph of constant current charging: Charging lights flashing, constant current charging at maximum.

Third constant voltage charging: Charging lights flashing, when the charging voltage is increased to a first set value, the current is automatically reduced down to the moment when the set value, transferred to the fourth paragraph.

Fourth paragraph of the constant current charging: floating lights flashing, constant trickle charge.

Fifth paragraph of the constant voltage charging: float lights flashing, when the voltage rises second set value, the current is automatically reduced down to the moment when the set value, transferred to the sixth paragraph.

Sixth paragraph vein rechargeyour: pulse charging lights flashing, the charging process for the charge 10 seconds stop 10 seconds. Charging complete panel LEDs light up.

Note: The second paragraph of the third set time of 8 hours, and the fourth paragraph of the fifth paragraph is set to 2 hours, 30 minutes, sixth paragraph, each turning point of the output current, output

Voltage, each time can be changed according to customer requirements.

Fourth, the use and precautions

1, when the battery indicator light indicates the battery polarity is correct, is not light that reversed.

2, please use the three-pin plug (with ground wire).

3, should be placed under safe working environment clean ventilation charged.

4, the fan does not turn failure or damage, please troubleshoot or replace the fan.

5, this applies only to lead-acid battery charger, different voltage and current charger can not be mixed.

6. Do not attempt to lengthen the input and output cables, causing the battery can not be charged.

7. If you disconnect the battery cables, must re-open the charger when the power switch is normally charged. (Otherwise the CPU program defaults

Is already full, the charger lights are lit)

8, rechargeable internal machine with high-pressure, non-professionals do not open.

9, during the warranty period, should ensure that the power cord and cables without damage, housing no distortion, no foreign objects inside the machine.

V. Dimensions: length 2900mm width 200mm height 95mm

6, installation dimensions: 170mm × 190mm 4 5mm mounting holes.

Seven Model:

48V25A 48V35A 60V35A 72V35A

Note: There are special needs of customers to order directly negotiate with us! ?
